RYD-S300 - Industrial Semi Automatic Liquid Filling Machine - 20-300ml

Technical Specifications of RYD-S100 - 5-100ml Liquid Filling Machine

General Features of RYD-S300 - 20-300ml Liquid Filling Machine

1. Fills all low and medium viscosity products from 20 ml to 300 ml.
2. Compared to traditional methods, it is a more hygienic, faster and more sensitive machine. Therefore, the fillings made with this machine are much more professional and suitable for industrial production.
3. The RYD-S300 industrial semi-automatic liquid filling machine has a flanged ferrule system at the connection points, allowing the machine to be easily disassembled and cleaned quickly.
4. All materials such as gaskets and seals at the points that come into contact with the product during liquid filling are made of anti-bacterial silicone material. Thus, you have established a system that meets hygiene requirements (GMP requirements).
5. 0.5 mm pitch precision dosing arm allows you to work with a single machine in many filling ranges with minimum drift rate. Unless the dosing setting is changed, it continues to operate at the same size.
6. The emergency button of the RYD-S300 industrial semi-automatic liquid filling machine allows the machine to be brought to a safe position in case of emergency, regardless of the position of the machine. In this way, you have a way of production in accordance with the occupational safety law numbered 6331. It does not require extra costs to make it compliant with the law in question.
7. It can be connected to the tank or tank drains with a clamp and can also suction from sources such as drums, buckets or buckets by immersion method. It does not require extra effort to bring the product to the mouth of the machine. This helps you save time.
8. You can operate the RYD-S300 industrial semi-automatic liquid filling machine in two different ways according to your production speed and format. You can either operate the machine in automatic mode with timer, or you can operate the machine in manual mode with the pedal provided free of charge with the machine.
9. The nozzle system has an anti-drip system. In this way, you will not experience dripping problems after the filling is completed. As a result, your filled bottles will not get dirty and you will not experience weight loss due to dripping.
10. Unlike other similar products, it has a honed product suction piston. This piston allows dosing with high precision even at high weights and minimizes filling waste. On the other hand, since the piston surface is smooth, the piston seals last longer than their counterparts.
11. The internal conditioner in the machine system provides protection against factors such as water and rust that may occur in the air installation and damage the pneumatic system of the machine. Thanks to the slide valve on the air inlet of the machine, you can cut off the air from the system when you are done with the machine without the need for a different valve.
12. Having an electro-pneumatic system provides the advantage of precise dosing and preventing weight wastage.
13. The earthing in the chassis of the machine protects the machine against electrical hazards that may occur in the body of the machine.
14. With the RYD-S300 industrial semi-automatic liquid filling machine, many liquids can be filled. Among the liquid types in question; fruit juice, water, turnip, low viscosity shampoo, liquid soap, bleach, milk, liquid oil, mineral oil, syrup, thinner and many other liquids.

Optional Features that can be added to RYD-S300 - 20-300ml Liquid Filling Machine

• The points in contact with the product can be produced from a different material according to your request and need.
• It can be produced in accordance with liquid fillings requiring high heat level.
• For foaming products such as milk and buttermilk for fast filling, a nozzle that can rise and fall during filling can be integrated into the system to increase your production speed.
• The sensor of the machine can be produced as triggered.
• Optionally, a counter can be added to show the number of products filled.
• It can be produced in different filling ranges according to your needs.
• The filling nozzles in the filling nozzles can be produced in different sizes according to the need.

RYD-S300 - Liquid Filling Machine 20-300ml - Other Details

• Product delivery varies between 5-20 days for non-standard productions.
• The machine is packaged in a way that is suitable for easy shipment over long distances.
• The machine you purchased can be delivered to your address at an affordable price with our contracted cargo. If you wish, shipment can also be made with your own contracted cargo company.
• The machine is guaranteed for 1 year against fabrication defects.
